Omni Cargo

RS 200

Regional All-Position

The RS 200 is a regional all-position, over-the road design well suited for urban applications.

Features:

  • This 18/32 tread depth tire promotes long mileage exception handling.
  • Wide footprint maximizes weight dispersion for even, uniform wear.
  • Wide primary grooves provide excellent water dispersion which improves handling in the harshest of conditions.
  • Cap Base construction with a multi-layer design will promote slow wear at the cap and a cool running rubber compound at the base extending the tires life in P&D applications .
  • Strategically placed siping minimizes free-rolling irregular wear and provides excellent water dispersion.
Size TT/TL PLY Load Index
Single
Load Index
Dual
Speed
Rating
Max Load
Single (LBS)
Max Load
DUAL (LBS)
Tread
Depth
32nds
Overall
Diameter
Section
Width
Rim
Width
Max
PSI
Revs
/Mile
Weight
(Lbs)
Static Load
Radius
Item
Code
11R22.5 TL 16 146 143 L 6614 6008 18 41.14 10.79 8.25 120 490 113.32 489 OMC9026
295/75R22.5 TL 16 146 143 L 6614 6008 18 39.72 11.54 9.00 120 508 111.77 472 OMC9071
*11R24.5 TL 16 149 146 L 7160 6610 18.00 43.31 11.22 8.25 120 466 117.95 516.0 OMC9117
*285/75R24.5 TL Specifications under development OMC9121

*Phase 2 sizes available Q4 2021
